Minimal Deviation Adenocarcinoma Associated with High-Grade Squamous Cervical Intraepithelial Neoplasia
Carlos Villegas-Cruz1#, Alhely López Arias2, Delia Pérez Montiel3#, José Chanona-Vilchis3, Luis Alonso Herrera Montalvo4* and David Cantú de León1*
1Departamento de Ginecología Oncológica, Instituto Nacional de Cancerología de México (INCan), Mexico
2Unidad de Investigaciones Biomédicas en Cáncer (UIBC), INCan, Instituto de Investigaciones Biomédicas (IIBM), Mexico
3Departamento de Patología, Instituto Nacional de Cancerología de México (INCan), Mexico
4Unidad de Investigaciones Biomédicas en Cáncer (UIBC), INCan, Instituto de Investigaciones Biomédicas (IIBM), Universidad Nacional Autónoma de México (UNAM), Mexico
*Corresponding authors: David Cantú de León, Departamento de Ginecología Oncológica, Instituto Nacional de Cancerología de México, Av. San Fernando No. 22, Col. Sección XVI, Tlalpan, 14080 México, D.F., México, Tel: (+52) (55) 5628 0400, email@example.com
Luis A. Herrera, Unidad de Investigaciones Biomédicas en Cáncer (UIBC), Instituto Nacional de Cancerología de México INCan), Instituto de Investigaciones Biomédicas (IIBM), Universidad Nacional Autónoma de México (UNAM), Av. San Fernando No. 22, Col. Sección XVI, Tlalpan, 14080 México, D.F., México, Tel: (+52) (55) 5628 0400, firstname.lastname@example.org
Obstet Gynecol Cases Rev, OGCR-2-047, (Volume 2, Issue 3), Case Report; ISSN: 2377-9004
Received: March 29, 2015 | Accepted: June 28, 2015 | Published: June 30, 2015
Citation: Villegas-Cruz C, Arias AL, Montiel DP, Chanona-Vilchis J, Montalvo LAH, et al. (2015) Minimal Deviation Adenocarcinoma Associated with High-Grade Squamous Cervical Intraepithelial Neoplasia. Obstet Gynecol Cases Rev 2:047. 10.23937/2377-9004/1410047
Copyright: © 2015 Villegas-Cruz C, et al. This is an open-access article distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited.
Background: Minimal deviation adenocarcinoma of the cervix is a rare neoplasm of difficult diagnosis due to its histological features, which are suggestive of being benign and seldom associated to Human Papilloma Virus (HPV).
Clinical case: We present the case of a 46 year old Mexican patient referred to our institution for the presence of abnormal cervical cytology, confirmed by biopsy of cervical squamous cell carcinoma in situ, who underwent cervical cone biopsy, which reported a minimal deviation adenocarcinoma 13mm in length and 7mm in depth with adenocarcinoma ans squeamous cell carcinoma in situ in the endocervical margins. The patient was undertaken to a Type C2 radical hysterectomy and a Level 2 bilateral lymphadenectomy plus bilateral salpingoophorectomy.
In the final pathology report no residual lesion was identified. The patient remains disease-free at follow-up.
Conclusions: The association of minimal deviation adenocarcinoma with a high-grade cervical intraepithelial neoplasm and high-risk papillomavirus is a rare event.
Cancer of the uterine cervix, Adenoma malignum, Cervical intraepithelial neoplasm
Cancer of the uterine cervix is the second cause of cancer at the worldwide level in women, with an incidence of 529,409 new cases annually and is the third place in mortality with 274,883 deaths; in Mexico it represents the second cause of cancer in women with 10,186 new cases each year and the second cause of cancer-related mortality with 5,061 cases, second only to breast cancer .
Most cervical epithelial cancers are squamous cell, adenocarcinoma of the cervix represents from 20-25% of all cervical carcinomas; within this subgroup is found minimal deviation adenocarcinoma, which represents 1-3% of all adenocarcinomas of the uterine cervix [2,3].
Squamous and glandular lesions are a frequent association; the proportion of adenocarcinomas in situ associated with intraepithelial neoplasms with high-grade squamous cervical intraepithelial neoplasms ranges from 24-75%, because both are found to be associated to Human papillomavirus (HPV) infection and are thought to be originated from the same reserve-cell type. However, minimal deviation adenocarcinoma is a neoplasm that is not associated with HPV infection, suggesting that may be originated from endocervical glandular hyperplasia, thus the rarity of its association with Cervical Intraepithelial Neoplasia (CIN) .
The objective of this case is to show the diagnostic difficulty that this combination of neoplasms may represent to the surgeons as well as for the pathologists.
This case concerns a Mexican female patient aged 46 years, without relevant medical or familial history, she was referred to the National Institute of Cancerology of Mexico (INCan) in January 2009 due to uterine cervix cytological screening test with the report of High-grade Squamous Intraepithelial lesion (HSIL). The colposcopic examination was considered abnormal due to the presence of an acetowhite lesion in the transformation zone that included the endocervical canal. The remainder of the colposcopic and pelvic examination was considered within normal limits. Cervical cytology reported an HSIL and the biopsy of squamous cell carcinoma in situ of the uterine cervix. A cone biopsy was performed and considered as therapeutic in March 2009. The final histopathological report of the cone was minimal deviation-type endocervical adenocarcinoma, tumor size was 13mm of horizontal extension and 7mm of depth of invasion, with neoplasm on the endocervical border and deep stromal border associated with squamous cell carcinoma in situ; the exocervical border was reported as neoplasm-free. (Figure 1-3).
Figure 1: Deep gland extension to stroma in cone specimen. View Figure 1
Figure 2: HE 20X component of in situ squamous cell carcinoma. View Figure 2
Immunohistochemistry was positive for P16, in HSIL and negative in endocervical adenocarcinoma. Ki67 was high in endocervical adenocarcinoma and HSIL components (Figure 4).
Figure 3: HE 40X minimal deviation adenocarcinoma, notice endocervical epithelium with mild atypia and frequent mitosis. View Figure 3
Figure 4: P16 stain. Positive in abnormal squamous epithelium and negative in minimal deviation adenocarcinoma. View Figure 4
With the previous report, the patient was staged as having an adenocarcinoma of the uterine cervix clinical stage Ib1. Extension studies were negative for metastasis and a decision was made to carry out a Type C2 radical hysterectomy and a Level 2 bilateral lymphadenectomy  plus bilateral salpingoophorectomy in April 2009, without complications, with the patient discharged from the hospital on postoperative day 3.
The final Pathology report revealed inflammation and cervical metaplasia without evidence of residual disease, 18 pelvic lymph nodes with hyperplasia without evidence of neoplastic cells, with the surgical-resection borders reported as negative for intraepithelial lesion.
During follow-up, HPV infection was documented in the vaginal cytology; hybrid capture was positive for high-risk HPV. Conservative treatment just with close follow-up was decided upon and at the patient's last visit in January 2012, colposcopy and vaginal cytology was found without lesions, solely reporting unspecific inflammatory changes.
Minimal deviation adenocarcinoma (MDA) of the uterine cervix is a rare neoplasia that is difficult to diagnose, was described for the first time in 1870; the term minimal deviation was coined in 1975 by Hurt and Silverberg [2,3].
The risk factors for this neoplasm are scarcely clear; despite the important relationship of HPV, mainly VPH 16 and -18, with carcinogenesis of the uterine cervix, in reports on MDA a relationship with the virus has not been identified [6-8]. What has been found is a relationship with the Peutz-Jeghers syndrome; in one series, 4 of 27 women with the latter syndrome developed MDA  and with lobular endocervical hyperplasia.
Average age at diagnosis is 45 years (range, 20-78 years); the clinical manifestations presented by the patients are the following: in 69.4% of cases, there is the presence of an aqueous or mucoid vaginal secretion; 50% of patients present irregular or abnormal vaginal bleeding, and in 24.5% of cases there is pelvic pain or urinary obstruction. In the majority of patients, the cervix tends to be thickened or with hypertrophy on macroscopic examination [8,10].
Cervical cytology as a diagnostic method for MDA has a detection rate of only 32.7% (10), with infrequent diagnosis by this method due to the well differentiated characteristics of the tumor cells in which there is scarce observation of atypias and the absence of a marker that could be used for differentiating tumor cells from the normal ones, as well as the scarce frequency of the neoplasm, which makes it not to be suspected . Due to that these lesions tend to be found in deep cervical layers, it is necessary to perform large biopsies with at least 7mm depth or greater, or to perform cervical cone biopsy to confirm the diagnosis .
In the report of Li et al. , 50.7% detection was documented with the performance of cervical biopsies in 185 patients and 100% detection in the 14 patients on whom cervical cone was carried out, therefore it seems that a cervical cone is the most reliable method to perform an accurate diagnosis.
The definitive diagnosis is based on the histopathological characteristics with the presence of glands varying in size and shape covered with a columnar epithelium with mucoproducer cytoplasm, predominately baseline nucleus or slight atypia, and the presence of stromal invasion. Most important for suspicion of the diagnosis is the localization of the glands below the level where these are normally found, that is, at a depth of >7mm; thus, it is important to take deep biopsies or even to perform a cervical cone in order to obtain a good sample of the lesion. Another histological datum that is of aid in diagnosis is the presence of mitosis in the apical part of the glands, because mitoses are very infrequent in normal endocervical epithelium.
The tumor-suppressor gene STK11 has been identified as responsible for the Peutz-Jeghers syndrome, an autosomal dominant disorder characterized by gastrointestinal hamartomatous polyps and mucocutaneous pigmentation, as a possible triggering effect in the development of MDA due to STK11 gene mutation and/or the loss of heterozygosity at the 19p13.3 locus of the gene [13,14].
Imaging studies such as transvaginal Ultrasound (US) as well as Computed Tomography (CT) tend to present multicystic cervical lesions, while by Magnetic Resonance Imaging (MRI) T2 sequence it is observed that in the majority of cases the presence of fine, non-cystic villi or hyperintense, multicystic lesions that extend from the endocervical glands to the deep stoma of the cervix . In the report of Itoh et al., on comparing the three techniques, the authors showed that MRI revealed the most detailed characteristics and best correlation with the histology ; however, differentiation or identification by lesion type is highly complicated, above all because multicystic lesions are easily confused with benign changes in the uterine cervix, such as Naboth´s cysts.
The co-existing presentation of an HSIL together with this adenocarcinoma variant is very rare, as previously mentioned  and due to the different carcinogenesis pathways, we infer that these are coincidental rather than related neoplasms.
Treatment for MDA is similar to that for any other adenocarcinoma of the cervix, limiting it to surgical treatment based on a Type C2 radical hysterectomy and a Level 2 bilateral lymphadenectomy (5) plus bilateral salpingoophorectomy at early clinical disease stages, as was performed in our patient, and similarly, it can be observed that the disease recurrence rate is influenced by the clinical stage. Chemotherapy plus radiotherapy is reserved for treatment at locally advanced clinical stages.
Minimal deviation adenocarcinoma of the uterine cervix is an entity that represents a challenge in terms of diagnosis, due to the low frequency of the neoplasm as well as to the histological complexity, it has been suggested by Gong et al that this tumor is a real neoplasm because of its clonal origin as well as it has not been related to HPV infection .
The combination of a HSIL associated with MDA is a much less frequent combination, which will render the clinician's initial treatment of the patient as if it were an adenocarcinoma in situ, which in the final analysis will not make the proposed treatment the adequate one.
Ferlay J, Shin HR, Bray F, Forman D, Mathers C, et al. (2010) Estimates of worldwide burden of cancer in 2008: GLOBOCAN 2008. Int J Cancer 127: 2893-2917.
Hart WR (2002) Symposium part II: special types of adenocarcinoma of the uterine cervix. Int J Gynecol Pathol 21: 327-346.
Randall ME, Michael H, Ver Morken J, Stehman F (2005) Uterine cervix. In: Hoskins WJ, Pérez CA, Young RC, Barakat RR, Markman M, et al. Principles and Practice of Gynecologic Oncology. Philadelphia: Lippincott Williams & Wilkins: 743-822.
Pirog EC, Kleter B, Olgac S, Bobkiewicz P, Lindeman J, et al. (2000) Prevalence of human papillomavirus DNA in different histological subtypes of cervical adenocarcinoma. Am J Pathol 157: 1055-1062.
Querleu D, Morrow CP (2008) Classification of radical hysterectomy. Lancet Oncol 9: 297-303.
Xu JY, Hashi A, Kondo T, Yuminamochi T, Nara M, et al. (2005) Absence of human papillomavirus infection in minimal deviation adenocarcinoma and lobular endocervical glandular hyperplasia. Int J Gynecol Pathol 24: 296-302.
An HJ, Kim KR, Kim IS, Kim DW, Park MH, et al. (2005) Prevalence of human papillomavirus DNA in various histological subtypes of cervical adenocarcinoma: a population-based study. Mod Pathol 18: 528-534.
Odashiro AN, Odashiro DN, Nguyen GK (2006) Minimal deviation endometrioid adenocarcinoma of the cervix: report of three cases with exfoliative cytology. Diagn Cytopathol 34: 119-123.
Young RH, Welch WR, Dickersin GR, Scully RE (1982) Ovarian sex cord tumor with annular tubules: review of 74 cases including 27 with Peutz-Jeghers syndrome and four with adenoma malignum of the cervix. Cancer 50: 1384-1402.
Li G, Jiang W, Gui S, Xu C (2010) Minimal deviation adenocarcinoma of the uterine cervix. Int J Gynaecol Obstet 110: 89-92.
Ishii K1, Katsuyama T, Ota H, Watanabe T, Matsuyama I, et al. (1999) Cytologic and cytochemical features of adenoma malignum of the uterine cervix. Cancer 87: 245-253.
Tsuda H, Mikami Y, Kaku T, Akiyama F, Hasegawa T, et al. (2003) Interobserver variation in the diagnosis of adenoma malignum (minimal deviation adenocarcinoma) of the uterine cervix. Pathol Int 53: 440-449.
Kuragaki C, Enomoto T, Ueno Y, Sun H, Fujita M, et al. (2003) Mutations in the STK11 gene characterize minimal deviation adenocarcinoma of the uterine cervix. Lab Invest 83: 35-45.
Lee JY, Dong SM, Kim HS, Kim SY, Na EY, et al. (1998) A distinct region of chromosome 19p13.3 associated with the sporadic form of adenoma malignum of the uterine cervix. Cancer Res 58: 1140-1143.
Doi T, Yamashita Y, Yasunaga T, Fujiyoshi K, Tsunawaki A, et al. (1997) Adenoma malignum: MR imaging and pathologic study. Radiology 204: 39-42.
Itoh K, Toki T, Shiohara S, Oguchi O, Konishi I, et al. (2000) A comparative analysis of cross sectional imaging techniques in minimal deviation adenocarcinoma of the uterine cervix. BJOG 107: 1158-1163.
Papastefanou I, Panagopoulos P, Samolis S, Karadaglis S, Katsoulis M (2010) Minimal deviation adenocarcinoma of the cervix in a patient with a high-grade cervical squamous intraepithelial lesion: case report and review of the literature. Eur J Gynaecol Oncol 31: 227-229.
Gong L, Zhang WD, Liu XY, Han XJ, Yao L, et al. (2010) Clonal status and clinicopathological observation of cervical minimal deviation adenocarcinoma. Diagn Pathol 5: 25.
